Christie's HDBaseT input Card is specifically for 4K7-HS and 4K10 HS models only. This input card extends the 4K video with HDR without any visual compromise or additional latency over a single CAT6 or CAT7 cable up to 100m. It complies with the HDCP 2.2 and HDMI 2.0 standards plus DVI 1.0 using an HDMI-DVI adapter.
Christie's HDBaseT input Card is specifically for 4K7-HS and 4K10 HS models only.
The HDBaseT 4K input card extends the 4K video with HDR without any visual compromise or additional latency over a single CAT6 or CAT7 cable up to 100m. It complies with the HDCP 2.2 and HDMI 2.0 standards plus DVI 1.0 using an HDMI-DVI adapter.
The HDBASET-INPUT-CARD slots into one of two expandable option card slots on the HS projectors and support is provided for HDCP 1.x and HDMI 1.x standards and variable RS232 Baud rates from 1200 bps to 115200 bps
It offers 16 bit deep colour up to 1080p@60Hz and HD resolutions up to 3840x2160@60Hz (YUV 4:4:4, 8 bit).
Please Note: The HDBaseT 4K input card does not support 14400 bps Baud rate or 4K HDR at Christie HS Series 4K7-HS and 4K10-HS products with 24Hz (YUV 4:4:4) and 60Hz (YUV 4:2:0) up to 12 bit colour. The 14400 Baud rate is not supported nor is half duplex 100Base-Tx.
This input card is not compatible with 4K22-HS model
Specifications:
Format
Pixel Clock (MHz)
Frame Rate (Hz)
Pixel Format
Bit Depth
Notes
3840x2160
594
50, 60
RGB
8-bit
-
3840x2160
594
50, 60
YCbCr 4:4:4
8-bit
-
3840x2160
371.25
50, 60
YCbCr 4:2:0
10-bit
4:2:0 formats going through DSC compression are output as 4:2:2 formats. 4:2:2 formats are always output as 12 bits
3840x2160
371.25
50, 60
YCbCr 4:2:0
10-bit HDR
4:2:0 formats going through DSC compression are output as 4:2:2 formats. 4:2:2 formats are always output as 12 bits
3840x2160
445.5
50, 60
YCbCr 4:2:0
12-bit
4:2:0 formats going through DSC compression are output as 4:2:2 formats
3840x2160
445.5
50, 60
YCbCr 4:2:0
12-bit HDR
4:2:0 formats going through DSC compression are output as 4:2:2 formats
3840x2160
594
50, 60
YCbCr 4:2:2
8 bit
4:2:2 formats are always output as 12 bits
3840x2160
594
50, 60
YCbCr 4:2:2
10-bit
4:2:2 formats are always output as 12 bits
3840x2160
594
50, 60
YCbCr 4:2:2
10-bit HDR
4:2:2 formats are always output as 12 bits
3840x2160
594
50, 60
YCbCr 4:2:2
12-bit
-
3840x2160
594
50, 60
YCbCr 4:2:2
12-bit HDR
-
3840x2160
371.25
25, 30
RGB
10-bit
-
3840x2160
445.5
25, 30
RGB
12-bit
-
3840x2160
371.25
25, 30
YCbCr 4:4:4
10-bit
-
3840x2160
371.25
25, 30
YCbCr 4:4:4
10-bit HDR
-
3840x2160
445.5
25, 30
YCbCr 4:4:4
12-bit
-
Features:
Complies with DVI 1.0 using an HDMI-DVI adapter
Complies with the HDCP 2.2 and HDMI 2.0 standards
Supports the legacy HDCP 1.x and HDMI 1.x standards
Supports RS232 baud rates from 1200 bps to 115200 bps
Simultaneously transmits data over a single CCAT6 and CAT7 cable up to distances of 100m
Supports 16 bit deep colour up to 1080p@60Hz
Supports HD resolutions up to 3840x2160@60Hz (YUV 4:4:4, 8 bit)
Please Note:
The HDBaseT 4K input card does not support 14400 bps Baud rate or 4K HDR at Christie HS Series 4K7-HS and 4K10-HS products with 24Hz (YUV 4:4:4) and 60Hz (YUV 4:2:0) up to 12 bit colour.
The 14400 Baud rate is not supported nor is half duplex 100Base-Tx.
